Features
- Feeding operation is same as printing press.
- Conveyor type is available for thick sheet and can be detected transparent sheet as it is equipped reflected/transmitted light suitable for film inspection.
- Inspection result shows on the display therefore easily adapt the failure on the spot.
- Connecting with printing press is able to detect after printing so that leads to reduce the failure.(Printing press option)
- Sorting unit which can reject the defective sheet is also available to connect.(Option)
Specifications
| SI-102 | SI-80 | |
|---|---|---|
| Max. sheet size (W x L) | 1,050 x 750 | 800 x 550 |
| Min. sheet size (W x L) | 420 x 297 | 350 x 270 |
| Sheet thickness | 0.1 - 0.8 | 0.1 - 0.8 |
| Camera resolution | 0.13 x 0.13 | 0.13 x 0.13 |
| Inspection speed | 800 - 2000 (SPH) | 400 - 2000 (SPH) |
| Number of camera | 2 | 2 |
